Improve oral bioavailability of poorly soluble APIs

Overcoming solubility challenges in oral drug development

For a growing share of new drug candidates, poor aqueous solubility remains one of the key barriers to translating promising active pharmaceutical ingredients into successful oral dosage forms. Specialty silica excipients help overcome this bottleneck: AEROPERL® 300 Pharma helps formulators improve the solubility and bioavailability of poorly water-soluble APIs, enabling more effective oral dosage forms and robust pharmaceutical manufacturing.

Good aqueous solubility of active pharmaceutical ingredients (APIs) is a key prerequisite for many drugs to achieve the intended effect in the body. APIs in oral dosage forms need to dissolve before they can permeate the intestinal membrane, enter the systemic circulation, and reach the blood concentration required for efficacy.

Yet a large and growing share of drugs are poorly water-soluble – making dissolution the limiting factor between a potential API and an effective medicine. That is why drug solubility and bioavailability are major formulation challenges in pharmaceutical development. AEROPERL® 300 Pharma offers a smart solution.

Drugs with low solubility BCS Class II and IV

According to a survey1, approximately 40% of marketed drugs exhibit low aqueous solubility, and up to 90% of new chemical entities face solubility challenges (BCS Class II and Class IV2).


Your presenter:
Carolina Mathias
Senior Applied Technical Manager Feed & Pharma,
Evonik Smart Effects
Your presenter: Carolina Mathias, Senior Applied Technical Manager Feed & Pharma Evonik Smart Effects

Join our webinar

“Revolutionize API formulation with AEROPERL® 300 Pharma – Unlocking solubility challenges“


Thursday, 26 November | 9:00 a.m. (CET)



Do not miss the chance to get first-hand information from our application technology experts about:


  • Solubility enhancement strategies for poorly water-soluble APIs
  • Application examples for BCS Class II and IV compounds
  • Lipid-based formulation approaches including SNEDDS
  • Tablet manufacturing and stability benefits
  • Case studies demonstrating formulation performance

AEROPERL® 300 Pharma boosts API bioavailability via solubility enhancement

For formulators working at the intersection of API selection and excipient design, AEROPERL® 300 Pharma is a versatile excipient that increases the dissolution of poorly water-soluble molecules, leading to high drug bioavailability.

The Biopharmaceutics Classification System (BCS) groups APIs into four different classes according to their permeability and solubility in aqueous media. Drugs categorized in class II and class IV of the BCS system have poor aqueous solubility, which is the limitation to achieve therapeutically necessary blood concentrations.

In  several case studies, AEROPERL® 300 Pharma has demonstrated the ability to improve the apparent solubility of BCS class II and class IV APIs, potentially shifting their biopharmaceutical performance toward higher BCS classes3, 4.

What is AEROPERL® 300 Pharma?

Smart Effects of AEROPERL® 300 Pharma

Improves dissolution performance and supports higher bioavailability of poorly water-soluble APIs (e.g. BCS class II and IV)

Converts liquid APIs and lipid formulations into free-flowing powders suitable for manufacturing andeasy tableting

Enhances mechanical tablet strength and protects APIs from moisture-induced degradation, ensuring long-term physical and chemical stability

Acts as an effective desiccant during wet granulation and moisture-activated dry granulation of oral solid dosage forms (OSDs)

Enhanced solubility for liquid, lipid and solid API preparations
Formulators benefit from flexibility in choosing oral solid dosage forms for drugs – e.g. tablet, powder sachet, or capsule – because the high surface area and mesoporous structure of AEROPERL® 300 Pharma enhance API presentation and dissolution regardless of formulation approach. AEROPERL® 300 Pharma converts liquid and solid APIs as well as lipid-based drug delivery systems into highly concentrated, free-flowing powders with improved solubility.

Lipid-based drug delivery systems (incl. self-nanoemulsified drug delivery technologies, SNEDDS): Loading fat-soluble active ingredients onto AEROPERL® 300 Pharma converts them into dry powders, enabling mechanically stable tablets with superior solubility and therefore increased bioavailability.4,5 Compared to inserting liquid lipid formulations into capsules, formulating with AEROPERL® 300 Pharma enables the more cost-efficient manufacturing of mechanically stable tablets with a longer shelf life.

Solid dispersion: AEROPERL® 300 Pharma is a mesoporous carrier for solvent or melt systems, stabilizing APIs in an amorphous state6,7 or smaller crystalline forms8 – enabling the production of mechanically stable tablets with superior solubility.

Micronized APIs: AEROPERL® 300 Pharma improves dissolution performance and promotes higher bioavailability by preventing particle agglomeration and maintaining a high effective surface area.

Why formulators choose AEROPERL® 300 Pharma

AEROPERL® 300 Pharma monograph compliance

AEROPERL® 300 Pharma is qualified following Ph. Eur, USP/NF & ChP and it is globally available.

Download technical data and formulation resources

Looking for formulation guidance and application examples?
Access formulation data, case studies, and development insights to accelerate your project.

Technical Information 1414

Technical Information 1415

Product Information

Ready to evaluate AEROPERL® 300 Pharma?

Whether you are developing a BCS Class II formulation, optimizing a lipid delivery system, or seeking to improve oral bioavailability, our experts can help.

Customer service executive working at office. Colleagues working in a call center. Beautiful business people in headsets are using computers and smiling while working in office.

Contact a formulation expert and book a technical consultation

Discuss your formulation challenge with our technical specialists and explore how AEROPERL® 300 Pharma can help improve API solubility, dissolution performance, and oral bioavailability.

Request a sample

Evaluate AEROPERL® 300 Pharma in your own formulation and process environment. Contact us today and start evaluating AEROPERL® 300 Pharma for your next formulation project.

Order your free sample here

References

1Bhalani DV, Nutan B, Kumar A, Singh Chandel AK. Bioavailability Enhancement Techniques for Poorly Aqueous Soluble Drugs and Therapeutics. Biomedicines. 2022 Aug 23;10(9):2055.

2Samineni R, Chimakurthy J, Konidala S. Emerging Role of Biopharmaceutical Classification and Biopharmaceutical Drug Disposition System in Dosage form Development: A Systematic Review. Turk J Pharm Sci. 2022 Dec 21;19(6):706-713.

3J. Münzenberg and S. Moller, "Improving the Dissolution of Poorly Soluble APIs with Inorganic Solid Dispersions," Pharmaceutical Technology Solid Dosage Drug Development and Manufacturing Supplement (April 2017).

4Abdelmonem R, Azer MS, Makky A, Zaghloul A, El-Nabarawi M, Nada A. Development, Characterization, and in-vivo Pharmacokinetic Study of Lamotrigine Solid Self-Nanoemulsifying Drug Delivery System. Drug Des Devel Ther. 2020 Oct 19; 14:4343-4362.

5Kazi, M.; Shahba, A.A.; Alrashoud, S.; Alwadei, M.; Sherif, A.Y.; Alanazi, F.K. Bioactive Self-Nanoemulsifying Drug Delivery Systems (Bio-SNEDDS) for Combined Oral Delivery of Curcumin and Piperine. Molecules 2020, 25, 1703.

6Qionghua Wei, Cornelia M. Keck, Rainer H. Müller, CapsMorph® technology for oral delivery – theory, preparation and characterization, International Journal of Pharmaceutics, Volume 482, Issues 1–2, 2015, Pages 11-20, ISSN 0378-5173

7Meer, T., Fule, R., Khanna, D. et al. Solubility modulation of bicalutamide using porous silica. Journal of Pharmaceutical Investigation 43, 279–285 (2013)

8Dwyer, L.; Kulkarni, S.; Ruelas, L.; Myerson, A. Two-Stage Crystallizer Design for High Loading of Poorly Water-Soluble Pharmaceuticals in Porous Silica Matrices. Crystals 2017, 7, 131.
